Dell 2135cn - Multifunction Color Laser Printer - Page 205

Installing the PHD Unit

1. Press the side button and open the front cover.

2. Turn the four PHD lock levers counterclockwise to unlock the unit.

3. Hold the gray tabs, and then pull the PHD unit out of the printer totally.

4. Completely remove the four yellow ribbons from the PHD unit.
NOTICE: Do not touch the belt unit.
NOTICE: Do not remove the protective sheet while removing the PHD unit.
