Dell 2135cn - Multifunction Color Laser Printer - Page 206


5. Insert the PHD unit until the line on the handle aligns with the white line on the printer.

6. Turn the four PHD lock levers 90 degrees in clockwise direction, and then remove the protective sheet.

7. Close the front cover.
Back to Contents Page

NOTICE: Pull the ribbons straight out of the unit.
NOTICE: Ensure that you do not hit the belt unit when inserting the PHD unit.
