About this task
NOTE: When replacing the palm-rest and keyboard assembly for computers with a M.2 2230 solid-state drive installed, ensure
that the M.2 2230 solid-state drive mounting bracket has been removed from the palm-rest and keyboard assembly and
installed on the new palm-rest and keyboard assembly.
NOTE: The replacement palm-rest and keyboard assembly is shipped with the speakers which are not pre-assembled to the
palm-rest and keyboard assembly. Before performing the post-requisites, follow step 1 to step 5 to install the speakers and
tweeters to the new palm-rest and keyboard assembly.
80
