Dell B5460dn User Manual

Note: Lift the tray slightly and pull it out.
2
3
1
2 Push down the front duplex flap, then firmly grasp the jammed paper, and then gently pull the paper to the right
and out of the printer.
Note: Make sure all paper fragments are removed.
2
1
3 Insert the tray.
4 From the printer control panel, select Next > > Clear the jam, press OK > to clear the message and continue
printing.
Clearing jams 155

Dell B5460dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Standard Memory	512 MB
Processor Speed	800 MHz
Monthly Duty Cycle	Up to 275, 000 pages
Connectivity	USB 2.0, Ethernet
Duplex Printing	Standard
First Page Out Time	4.4 seconds
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Linux
Input Capacity	650 sheets (standard); 4, 400 sheets (maximum)
