[x]page jam, remove paper, open expander rear door. Leave
paper in bin. [43y.xx]
1 Open the rear door of the highcapacity output expander.
2 Firmly grasp the jammed paper on each side, and then gently pull it out.
Note: Make sure all paper fragments are removed.
3 Close the rear door of the highcapacity output expander.
4 From the printer control panel, select Next > > Clear the jam, press OK > to clear the message and continue
printing.
Clearing jams 160
