Dell B5460dn User Manual

[x]‑page jam, open tray [x]. [24x]
1 Check which tray is indicated on the printer display, and then pull the tray.
1
2 Firmly grasp the jammed paper on each side, and then gently pull it out.
Note: Make sure all paper fragments are removed.
1
3 Insert the tray.
4 From the printer control panel, select Next > > Clear the jam, press OK > to clear the message and continue
printing.
[x]‑page jam, clear manual feeder. [250]
1 From the multipurpose feeder, firmly grasp the jammed paper on each side, and then gently pull it out.
Clearing jams 156

Dell B5460dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Standard Memory	512 MB
Processor Speed	800 MHz
Monthly Duty Cycle	Up to 275, 000 pages
Connectivity	USB 2.0, Ethernet
Duplex Printing	Standard
First Page Out Time	4.4 seconds
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Linux
Input Capacity	650 sheets (standard); 4, 400 sheets (maximum)
