Dell B5460dn User Manual

To install a printer hard disk onto the ISP:
a Remove the screws attached to the printer hard disk mounting bracket, and then remove the bracket.
b Align the standoffs of the printer hard disk to the holes in the ISP, and then press the printer hard disk down
until the standoffs are in place.
Installation warning: Hold only the edges of the printed circuit board assembly. Do not touch or press on
the center of the printer hard disk. Doing so may cause damage.
c Insert the plug of the printer hard disk interface cable into the receptacle of the ISP.
Note: The plugs and receptacles are color‑coded.
Additional printer setup 25

Dell B5460dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Standard Memory	512 MB
Processor Speed	800 MHz
Monthly Duty Cycle	Up to 275, 000 pages
Connectivity	USB 2.0, Ethernet
Duplex Printing	Standard
First Page Out Time	4.4 seconds
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Linux
Input Capacity	650 sheets (standard); 4, 400 sheets (maximum)
