Dell B5460dn User Manual

Use To
Configure Bins
Mailbox
Link
Mail Overflow
Link Optional
Type Assignment
Specify configuration options for bins.
Notes:
• Mailbox is the factory default setting. This setting
treats each bin as a separate mailbox.
• Link configures all available bins as one large bin.
• Mail Overflow configures each bin as a separate
mailbox.
• Link Optional links all available bins except the
standard bin and only appears when at least two
optional bins are installed.
• Type Assignment assigns each paper type to a bin or
linked bin set.
• Bins assigned the same name are automatically
linked unless Link Optional is selected.
Overflow Bin
Standard Bin
Bin [x]
Specify an alternative bin when a designated bin is full.
Notes:
• Standard Bin is the factory default setting.
• If multiple bins are assigned the same name, then the
name only appears once in the bin list.
• [x] can be any number between 1 and 12 if the
appropriate optional bins are installed.
Assign Type/Bin
Plain Paper Bin
Card Stock Bin
Transparency Bin
Recycled Bin
Labels Bin
Vinyl Labels Bin
Bond Bin
Envelope Bin
Rough Envelope Bin
Letterhead Bin
Preprinted Bin
Colored Bin
Light Paper Bin
Heavy Paper Bin
Rough/Cotton Bin
Custom [x] Bin
Select a bin for each supported paper type.
For each type, select the following options:
Disabled
Standard Bin
Bin [x]
Notes:
• Disabled is the factory default setting.
• [x] can be any number between 1 and 12 if the
appropriate optional bins are installed.
• If multiple bins are assigned the same name, then the
name only appears once in the bin list.
Understanding the printer menus 85

Dell B5460dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Standard Memory	512 MB
Processor Speed	800 MHz
Monthly Duty Cycle	Up to 275, 000 pages
Connectivity	USB 2.0, Ethernet
Duplex Printing	Standard
First Page Out Time	4.4 seconds
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Linux
Input Capacity	650 sheets (standard); 4, 400 sheets (maximum)
