10 | About your monitor
Side view
2
3
4
5
6
7
8
9
11
12
1
10
Label Description Use
1 Audio line-out port Connect to external audio peripherals.
Only supports 2-channel audio.
NOTE:
The audio line-out port does not
support headphones.
2 Audio line-in port Analog audio (two channel) input.
3 VGA connector Connect your computer with VGA cable.
4 DP connector Connect your computer with DP cable.
5 HDMI 1 connector
Connect your computer with HDMI cable.
6 HDMI 2 connector
7 USB dedicated
charging port
USB 3.0 with 10 W - Power supply (5 V/2.0 A)
8 USB 3.0
downstream port
Connect your USB device.
You can only use this connector after you have
connected the USB cable to the computer and
USB upstream connector on the monitor.
