Dell Dimension 3100 - Page 65

Removing and Installing Parts 63
4 Locate the three hinge tabs on the bottom edge of the computer.
5 Grip the sides of the computer cover and pivot the cover up, using the bottom hinges as
leverage points.
6 Release the cover from the hinge tabs and set it aside in a secure location.
computer cover
cover latch release
back of computer
bottom hinges
