76 Removing and Installing Parts
Replacing the Drive Panel
1
Follow the procedures in "Before You Begin" on page 57.
2
Align the drive panel tabs with the side-door hinges.
3
Rotate the drive panel toward the computer until it snaps into place on the front panel.
4
Grasp the sliding plate lever and pull it towards the top of the computer, snapping it into the
closed position to secure the drive panel.
Drives
Your computer supports a combination of these devices:
• Up to two serial ATA hard drives
• One FlexBay drive (floppy drive or Media Card Reader)
• Up to two CD or DVD drives
drive panel
sliding plate
sliding plate lever
