Dell Dimension 3100 - Removing a Hard Drive

80 Removing and Installing Parts
Removing a Hard Drive
1 Follow the procedures in "Before You Begin" on page 57.
2 Disconnect the power and hard-drive cables from the drive.
3 Press in the blue tabs on each side of the drive towards each other and slide the drive up and
out of the computer.
serial ATA
data cable
power cable
tabs (2)
hard drive
