100 Removing and Installing Parts
6
If you are installing a new floppy drive rather than replacing a drive, remove the appropriate drive-panel
insert (see "Removing the Drive-Panel Insert" on page 87).
7
Check all cable connections, and fold cables out of the way to avoid blocking airflow between the fan
and cooling vents.
8
Replace the drive panel (see "Replacing the Drive Panel" on page 89).
9
Replace the computer cover (see "Replacing the Computer Cover" on page 110).
NOTICE: To connect a network cable, first plug the cable into the network device and then plug it into the
computer.
10
Connect your computer and devices to their electrical outlets, and turn them on.
See the documentation that came with the drive for instructions on installing any software required for
drive operation.
1 power cable 2 data cable
1
2
