86 Removing and Installing Parts
Drive Panel
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product
Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before
removing the cover.
Removing the Drive Panel
1
Follow the procedures in "Before You Begin" on page 65.
2
Remove the computer cover (see "Removing the Computer Cover" on page 66).
1 sliding plate lever 2 sliding plate 3 drive panel
4 side hinges
3
2
1
4
