Dell Dimension E521 User Manual

Removing and Installing Parts 105
Removing a CD/DVD Drive
1 Follow the procedures in "Before You Begin" on page 65.
2 Remove the drive panel (see "Removing the Drive Panel" on page 86).
3 Disconnect the power cable and the CD/DVD drive data cable from the back of the drive and the
system board.
1 power cable 2 data cable
1
2
