Removing and Installing Parts 73
3
Align the notch on the bottom of the module with the crossbar in the connector.
NOTICE: To avoid damage to the memory module, press the module straight down into the connector while you
apply equal force to each end of the module.
4
Insert the module into the connector until the module snaps into position.
If you insert the module correctly, the securing clips snap into the cutouts at each end of the module.
5
Replace the computer cover.
NOTICE: To connect a network cable, first plug the cable into the network device and then plug it into the
computer.
6
Connect your computer and devices to electrical outlets, and turn them on.
7
Right-click the
My Computer
icon and click
Properties
.
8
Click the
General
tab.
9
To verify that the memory is installed correctly, check the amount of memory (RAM) listed.
1 cutouts (2) 2 memory module 3 notch
4 crossbar
3
2
1
4
