Processor
CAUTION: Before you perform this procedure, follow the safety instructions in your Owner's Manual.
Installing the Processor
NOTE: It is recommended that only a technically knowledgeable person perform this
procedure.
CAUTION: The processor can get very hot during normal operation. Ensure that the processor has had
sufficient time to cool before you touch it.
1. Follow the instructions in "Before You Begin."
2. Open the computer cover.
3. Remove the processor airflow shroud.
If you are replacing a processor, follow steps 4, 5, and 6 in "Removing the Processor."
NOTICE: You must position the processor correctly in the socket to avoid permanent damage to the processor and
the computer.
4. If the release lever is not extended to the release position, move it to that position.
5. Align pin-1 (the imprinted corner) of the processor and pin-1 of the socket.
NOTICE: Processor pins are delicate. To avoid damage, ensure that the processor aligns properly with the socket, and
do not use excessive force when you install the processor.
6. Carefully set the processor in the socket and press it down lightly to seat it.
7. Rotate the release lever back toward the system board until it snaps into place, securing the processor.
