40 Operating your monitor
Icon Menu and submenus Description
Display Use the display to adjust image.
Aspect Ratio Adjust the image ratio to 16:9, 4:3, or 5:4.
Horizontal Position
(VGA input only)
Use or to move image left and right.
Minimum is '0' (-). Maximum is '100' (+).
Vertical Position
(VGA input only)
Use or to move image up and down.
Minimum is '0' (-). Maximum is '100' (+).
Sharpness This feature can make the image look sharper or softer.
Use or to adjust the sharpness from 0 to 100.
Pixel Clock
(VGA input only)
The Pixel Clock feature enables you to adjust image quality on your monitor according to
your preference.
Use or buttons to adjust for best image quality.
Phase
(VGA input only)
If satisfactory results are not obtained using the Phase adjustment, use the Pixel Clock
(coarse) adjustment and then use Phase (fine), again.
Response Time Allows you to select between Normal (8 ms), Fast (5 ms).
Reset Display Select this option to restore default display settings.
