Figure 64. Removing and installing a processor
1
pin-1 indicator of processor 2 processor
3 slot (2) 4 processor shield
5 socket lever 6 socket keys (2)
7 socket
Next steps
1 Install the processor.
2 Install the heat sink.
3 Follow the procedure listed in the After working inside your system section.
Related links
Removing the cooling shroud
Removing the heat sink
Installing the processor
Installing the heat sink
Installing the cooling shroud
Installing the processor
Prerequisites
CAUTION
: Many repairs may only be done by a certied service technician. You should only perform troubleshooting and simple
repairs as authorized in your product documentation, or as directed by the online or telephone service and support team.
Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
NOTE: This is a Field Replaceable Unit (FRU). Removal and installation procedures should be performed only by Dell certied
service technicians.
108 Installing and removing system components
