Figure 47. Installing a cooling fan blank
Next step
Follow the procedure listed in the After working inside your system section.
Removing a cooling fan
Prerequisites
NOTE
: The procedure for removing each fan is identical.
1 Follow the safety guidelines listed in the Safety instructions section.
2 Follow the procedure listed in the Before working inside your system section.
3 Remove the cooling shroud.
4 If required, remove the cooling shroud.
Steps
1 Disconnect the power cable from the power connector on the system board by pressing the sides of the power cable.
2 Lift the fan out of the cooling fan bracket.
90
Installing and removing system components
