Dell E33S001 - Installing the Expansion Card Riser

Figure 52. Removing and installing the expansion card riser
1
expansion card riser 2 touch point (2)
3 expansion card latch 4 guide slot on the chassis
5 riser connector on the system board 6 guide pin on the system board
7 guide slot on the expansion card riser
Next steps
1 Install the expansion card riser.
2 Follow the procedure listed in the After working inside your system section.
Related links
Removing an expansion card
Installing an expansion card
Installing the expansion card riser
Installing the expansion card riser
Prerequisites
1 Follow the safety guidelines listed in the Safety instructions section.
2 Follow the procedure listed in the Before working inside your system section.
3 Install the expansion card into the expansion card riser.
96
Installing and removing system components
