CAUTION: To prevent damage to the memory module or the memory module socket during installation, do not bend or ex
the memory module; insert both ends of the memory module simultaneously.
2 Align the edge connector of the memory module with the alignment key of the memory module socket, and insert the memory module
in the socket.
NOTE: The memory module socket has an alignment key that enables you to install the memory module in the socket in only
one orientation.
CAUTION: Do not apply pressure at the center of the memory module; apply pressure at both ends of the memory module
evenly.
3
Press the memory module with your thumbs until the socket levers rmly click into place.
When the memory module is properly seated in the socket, the levers on the memory module socket align with the levers on the other
sockets that have memory modules installed.
Figure 25. Installing the memory module
1
memory module 2 alignment key
3 memory module socket ejector (2)
Next steps
1 Install the cooling shroud.
2 Follow the procedure listed in the After working inside your system section.
3 To enter System Setup, press F2 and check the System Memory setting.
The System Memory Size indicates the installed memory.
4 If the System Memory Size is incorrect, one or more of the memory modules may not be installed properly. Ensure that the memory
modules are rmly seated in their sockets.
5 Run the system memory test in the system diagnostics.
