Feature
1. Cable routing slot Route any cable(s) that has to be
connected to the PCI card installed in
the I/O module.
2. RS232 port Connect a RS2325 cable.
3. GPIO port Connect a GPIO 8–pin cable.
4. USB 2.0 port For USB 2,0 devices
5. USB 2.0 port For USB 2,0 devices
6. Top release-latch Push both the top and bottom release-
latch to disconnect the power module
from the Dell Edge Gateway.
7. I/O module expansion
connector and guide pin
Connect the I/O module to the Dell
Edge Gateway.
8. Power status light Indicates the power state of the I/O
module and the Dell Edge Gateway.
9. Bottom release-latch Push both the top and bottom release-
latch to disconnect the power module
from the Dell Edge Gateway.
10. PCIe x1 card slot Install PCIe x1 card on the I/O module.
11. I/O module cover removal
screw
Remove the screw to open the box and
install the PCIe card.
Setting up the I/O Module
CAUTION: Before touching anything inside the system, ground
yourself by touching an unpainted metal surface. While you work,
periodically touch an unpainted metal surface to dissipate static
electricity, which could harm internal components.
NOTE: Install the PCIe expansion card in the I/O Expansion Module
before mounting it on Wall mount or DIN rail.
1 Install the PCIe expansion card in the I/O Expansion Module - optional
