10 Close and securely latch the Enclosure door.
Specifications - Enclosure
Dimensions
Height 397 mm (15.62 inches)
Width 443.40 mm (17.46 inches)
Depth 79.80 mm (3.14 inches)
NOTE: The dimensions do not include the latches and wall bracket on
back of enclosure; the wall bracket adds 5 mm to the depth.
Environmental requirements
Ingress Protection Rating
IP65
NOTE: Require IP65 or above
conduit connection.
Temperature range:
60
