• Calculate the total length of wire from the battery to the system.
• Determine current-carrying capacity in the wire.
• Determine correct wire gauge in the intersection of amps and feet.
Specifications - Power Module
Dimensions
Height 117.80 mm (4.64 inches)
Width 216 mm (8.50 inches)
Depth 64.20 mm (2.53 inches)
48
