Feature
8. Micro-SIM card slot Insert a micro-SIM card to connect to a
mobile broadband network.
9. Mobile broadband antenna
port (port one)
Connect an antenna to increase the
range and strength of the mobile
broadband signals.
10. Power module expansion port Connect an external power module for
increased power options.
11. +24V AC/DC power Phoenix
connector
Connect a +24V AC/DC power
connector to provide power to your
system
12. +19.5 VDC power adapter
port
Connect a +19.5 VDC power adapter
connector to provide power to your
system
13. Power button Press and hold for 2 seconds to turn on
the system if it is turned off.
14. Earth ground Connect the grounding cable to the
system
15. Serial port Connect to a serial port enabled device
like printers and so on.
16. CANbus port Connect to a CANbus port enabled
device or dongles.
17. RS422/485 port Connect a RS422/485 device.
18. RS485 port Connect a RS422 device.
19. RS485 port Connect a RS485 device.
20. USB 3.0 port For USB 3.0 devices
21. Network port Connect an Ethernet (RJ45) cable from
a router or a broadband modem for
network or internet access.
22. Network port Connect an Ethernet (RJ45) cable from
a router or a broadband modem for
network or internet access.
23. I/O expansion port Connect an external expansion module
for additional I/O ports.
7
