Figure 8. Installing a drive
The activity light flashes to indicate that the spin-up sequence has begun.
Installing the front bezel
Prerequisites
CAUTION:
If the protective plastic strip is present on the front of the bezel, it must be removed before placing the
system into operation. Failure to remove the protective plastic strip will cause the system to overheat.
About this task
Refer to Figure 9. Installing the bezel while performing the procedure that follows.
Steps
1. If present, remove the protective plastic strip from the front of the bezel.
2. Align the bezel with the enclosure.
3. Gently push the bezel into place on the cabinet until it latches.
4. If the bezel has a key lock, lock the bezel with the provided key.
Figure 9. Installing the bezel
Install a new base enclosure and optional expansion enclosure
17
