Prerequisites
The following is a list of components needed for successful installation of the Z9100-ON:
NOTE: Detailed installation instructions for the Z9100-ON are provided in Site Preparations and Install the Z9100-ON.
● Z9100–ON switch, or multiple switches if stacking
● AC or DC country- and regional-specific cables. Used to connect the AC or DC power source to each of the switches’ AC or
DC power supplies.
● ReadyRail™ mounting brackets for rack installation, included
●
Screws for rack installation
● #1 and #2 Phillips screwdrivers, not included
● Ground cable screws for L-bracket, included
● Copper and fiber cables
Other components are:
● Ground cable screw, M3 or M4 depending on your switch
● Extra mounting brackets
Z9100–ON configurations
You can order the Z9100–ON switch in several configurations.
You can order the following supported hardware components:
● Z9100–ON AC or DC normal airflow: thirty–two 10/25/40/50/100 GbE ports with two SFP+ 10 GbE ports, two AC or DC
power supply and five fan subsystems. Airflow is from the I/O side to the power supply side.
● Z9100–ON AC or DC reverse airflow: thirty–two 10/25/40/50/100 GbE ports with two SFP+ 10 GbE ports, two AC or DC
power supply and five fan subsystems. Airflow from the power supply side to the I/O side.
● Fan with airflow from the I/O side to the PSU side—normal airflow
● Fan with airflow from the PSU side to the I/O side—reverse airflow
● AC or DC power supply with airflow from the I/O side to the PSU side—normal airflow
● AC or DC power supply with airflow from the PSU side to the I/O side—reverse airflow
10
The Z9100–ON switch
