Table 8. Environmental parameters (continued)
Parameter Specifications
Storage temperature –40° to 158°F (–40° to 70°C)
Storage humidity 5 percent to 90 percent, non-condensing
Maximum thermal output 292.42 BTU/hr 85.7 W
Maximum operational altitude 10,000 feet (3,048 meters)
Maximum non-operational altitude 39,370 feet (12,000 meters)
Shock SV0115 — ODM
Table 9. AC power requirements
Parameter Specifications
Power supply 100–240 VAC 50/60 Hz
PSU maximum power capability 606 Watts
Typical power consumption 288 Watts
Table 10. DC power requirements
Parameter Specifications
Minimum and maximum input voltage range −48, –60V DC, 32A Max
Input power at full load
−40.5 V/970 W −48 V/930 W −60 V/950 W (without fan)
−40.5 V/980 W −48 V/940 W −60 V/960 W (with fan)
Input current at full load
−40.5V/23.8A −48V/19.0A −60V/15.6A (without fan)
−40.5V/24.0A −48V/19.2A −60V/16.0A (with fan)
Start up VDC 39.0+/−1.5 V
Start off VDC 37.5+/−1.5 V
IEEE standards
The Z9100–ON complies with the following IEEE standards.
● 802.3ab Gigabit Ethernet (1000BASE-T)
● 802.3ae 10 Gigabit Ethernet (10GBASE-X)
● 802.3ba 40 Gigabit Ethernet (40GBase-SR4, 40GBase-CR4) on optical ports
●
802.3ba 100 Gigabit Ethernet
● 802.3bj 100 Gigabit Ethernet
● 802.3bm 100 Gigabit Ethernet
Agency compliance
The Z9100–ON is designed to comply with the following safety and agency requirements.
USA Federal Communications Commission statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
rules. These limits are designated to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy. If it is not installed and
40
