2. Follow the procedure listed in Before working inside your system.
3. Remove the expansion card riser.
4. If applicable, disconnect the power or data cables from the expansion card(s).
Steps
1. To remove the battery:
a. Use a plastic scribe to pry out the system battery.
Figure 82. Removing the system battery
CAUTION:
To avoid damage to the battery connector, you must firmly support the connector while installing
or removing a battery.
2. To install a new system battery:
a. Hold the battery with the positive side facing up and slide it under the securing tabs.
b. Press the battery into the connector until it snaps into place.
Installing and removing system components
77
