Dell EMC XC Core XC450 User Manual

Table 1. Features available on the front of the system (continued)
Item Ports, panels, and
slots
Icon Description
troubleshooting the system. For more information, see the
Integrated Dell Remote Access Controller User's Guide
available at https://www.dell.com/idracmanuals.
2 Drive N/A Enables you to install drives that are supported on your system.
3 Right control panel N/A Contains the power button, USB port, iDRAC Direct micro port,
and the iDRAC Direct status LED.
4 Information tag N/A
The Information tag is a slide-out label panel that contains
system information such as Service Tag, NIC, MAC address,
and so on. If you have opted for the secure default access
to iDRAC, the Information tag also contains the iDRAC secure
default password.
5 Drive blank N/A
Enables you to install drives that are supported on your system.
Figure 2. Front view of 8 x 2.5-inch drive system
Rear view of the system
Figure 3. Rear view of the system
Table 2. Features available on the rear of the system
Item Ports, panels, or slots Icon Description
1 PCIe expansion card riser
1
N/A Enables you to connect PCI Express expansion cards.
8 Dell EMC XC Core XC450 system overview
