10 | The E300 System
www.dell.com | support.dell.com
Figure 2-2. E300 Chassis Rear View with AC Power Supplies
Figure 2-3. E300 Chassis Rear View with DC PEMs
Table 2-1 lists the minimum and maximum components required to run the E300 System.
Optional Grounding
Holes
AC Power Supply
AC Power Supply
LEDs
fn00121a
A
ir Filter
Power
Inlet Socket
Standby Switch
Optional Grounding
Holes
fn00121cHH
A
ir Filter
DC Power Supply
Slot 0
DC Power Supply
Slot 1
