RPM Ports and Cables | 41
You can connect to the console using a RJ-45 to RJ-45 rollover cable and a RJ-45 to DB-9 female DTE
adapter (labeled “TERMINAL”) to a terminal server (for example, PC). The table below list the pin
assignments.
Accessing the Console with a DB-25 Adapter
You can connect to the console using a RJ-45 to RJ-45 rollover cable and a RJ-45 to a DB-25 female DTE
adapter.
Table 8-4
lists the pin assignments.
You can connect to the console using a RJ-45 to RJ-45 rollover cable and a RJ-45 to a DB-25 female DTE
adapter. The table below lists the pin assignments.
Accessing the Auxiliary Port by Modem
You can access the auxiliary port using a dial-up modem using a RJ-45 to RJ-45 rollover cable and a RJ-
45 to a DB-25 male DCE adapter (labeled “MODEM”).
Table 8-5
lists the pin assignments.
Table 8-3. Pin Assignments Between the E300 Console and a DTE Terminal Server
E300 System
Console Port
RJ-45 to RJ-45 Rollover Cable RJ-45 to DB-9
Adapter
Terminal Server
Device
Signal RJ-45 pinout RJ-45 Pinout DB-9 Pin Signal
RTS 1 8 8 CTS
DTR 2 7 6 DSR
TxD 3 6 2 RxD
GND 4 5 5 GND
GND 5 4 5 GND
RxD 6 3 3 TxD
DSR 7 2 4 DTR
CTS 8 1 7 RTS
Table 8-4. Pin Assignments Between E300 Console and DB-25 Adapter
E300 System
Console Port
RJ-45 to RJ-45 Rollover Cable RJ-45 to DB-25
Modem Adapter
Terminal Server
Device
Signal RJ-45 Pinout RJ-45 Pinout DB-25 Pinout Signal
RTS 1 8 5 CTS
DTR 2 7 6 DSR
TxD 3 6 3 RxD
GND 4 5 7 GND
GND 5 4 7 GND
RxD 6 3 2 TxD
DSR 7 2 20 DTR
CTS 8 1 RTS
