Orderable Z9000 Components
You can order the Z9000 in several different configurations. You can also order optional modules and
optics separately.
Table 2-1. Supported Hardware Components
Hardware Force10 Catalog Number Dell Part Number
32-port 40G QSFP+ ports, 1 AC power supply, 1 fan subsystem
(airflow from the I/O side to the power supply side)
Z9000-AC K9N70
32-port 40G QSFP+ ports, 1 AC power supply, 1 fan subsystem
(airflow from the power supply side to the I/O side)
Z9000-AC-R GJKPG
32-port 40G QSFP+ ports, 1 DC power supply, 1 fan subsystem
(airflow from the I/O side to the power supply side)
Z9000-DC G9TXN
32-port 40G QSFP+ ports, 1 DC power supply, 1 fan subsystem
(airflow from the power supply side to the I/O side)
Z9000-DC-R HRXFM
Z9000 Series – Fan with airflow from the I/O side to the PSU side Z9000-FAN WWJVT
Z9000 Series – Fan with airflow from the PSU side to the I/O side Z9000-FAN-R FRD2C
Z9000 Series – AC Power supply with airflow from the I/O side
to the PSU side
Z9000-PWR-AC NY1X9
Z9000 Series – AC Power supply with airflow from the PSU side
to the I/O side
Z9000-PWR-AC-R 0XRVV
Z9000 Series – DC Power supply with airflow from the I/O side
to the PSU side
Z9000-PWR-DC 4JPXV
Z9000 Series – DC Power supply with airflow from the PSU side
to the I/O side
Z9000-PWR-DC-R F3WK0
Z9000 Series – Solid State Drive (SSD) Z9000-SSD 2HYHT
Table 2-2. Supported Optics and Cables
Optic Size Optic Type Reach (Meters) Force10 Catalog Number Dell Part
Number
40Gig
40G QSFP+ ESR Optics module 300 M (OM3 fiber)
400 M (OM4 fiber)
N/A 0MV31
QSFP+ short reach optics 100 M (OM3 fiber)
150 M (OM4 fiber)
GP-QSFP-40GE-1SR RF2MY
Active Fiber Direct attach cable 10 M
50 M
CBL-QSFP-40GE-10M
CBL-QSFP-40GE-50M
0C2YV
9JT65
Passive Copper Direct attach cable 1 M
5M
CBL-QSFP-40GE-PASS-1M
CBL-QSFP-40GE-PASS-5M
NWGTV
V492M
QSFP+
Breakout
Cable
40GE QSFP+ to 4 SFP+ passive
breakout cable (optics not included)
5 M CBL-QSFP-4x10GSFP-PASS-
5M
HVVVF
40GE QSFP+ to 4 SFP+ optical cable
(optics not included)
5 M CBL-QSFP-4x10GSFP-5M 1X3JJ
