Dell Latitude 3380 User Manual

Option Description
• Set battery threshold (15% to 100%) - 15 % (enabled by default)
Advanced Battery
Charge
Conguration
This option enables you to maximize the battery health. By enabling this option, your system uses the standard
charging algorithm and other techniques during the nonwork hours to improve the battery health.
Disabled
Default setting: Disabled
Primary Battery
Charge
Conguration
Allows you to select the charging mode for the battery. The options are:
• Adaptive—enabled by default
• Standard—Fully charges your battery at a standard rate.
• ExpressCharge—The battery charges over a shorter time using Dell’s fast charging technology This option is
enabled by default.
• Primarily AC use
• Custom
If Custom Charge is selected, you can also congure Custom Charge Start and Custom Charge Stop.
NOTE: All charging mode may not be available for all the batteries. To enable this option, disable the
Advanced Battery Charge Conguration option.
Sleep mode
• OS Automatic selection
• Force S3—enabled by default
POST behavior screen options
Option
Description
Adapter Warnings Allows you to enable or disable the system setup (BIOS) warning messages when you use certain power adapters.
Default setting: Enable Adapter Warnings
Numlock Enable Allows you to enable the Numlock option when the computer boots.
Enable Network. This option is enabled by default.
Fn Lock Options
Allows you to let hot key combinations Fn + Esc toggle the primary behavior of F1–F12, between their standard
and secondary functions. If you disable this option, you cannot toggle dynamically the primary behavior of these
keys. The available options are:
• Lock Mode Disable/Standard—enabled by default
• Lock Mode Enable
Fastboot Allows you to speed up the boot process by bypassing some of the compatibility steps. The options are:
• Minimal—enabled by default
• Thorough
• Auto
Extended BIOS
POST Time
Allows you to create an extra preboot delay. The options are:
• 0 seconds—enabled by default.
• 5 seconds
52 System setup options

Dell Latitude 3380 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Market positioning	Educational
Memory slots	1x SO-DIMM
Internal memory	4 GB
Memory clock speed	2133 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
3D	No
AC adapter included	Yes
HDD size	2.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
Pixel pitch	0.2148 x 0.2148 mm
Display surface	Matt
Display diagonal	13.3 \
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x5906
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 610
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	900 MHz
Audio chip	Realtek ALC3246
Speaker power	2 W
Number of built-in speakers	2
Front camera resolution	1280 x 720 pixels
Front camera resolution (numeric)	1 MP
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Operating system architecture	64-bit
Battery voltage	11.4 V
Battery capacity	56 Wh
Number of battery cells	4
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.34 A
AC adapter output voltage	19.5 V
Cable lock slot type	Noble
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Bus type	OPI
Tjunction	100 °C
Processor cache	2 MB
System bus rate	4 GT/s
Processor family	Intel® Celeron®
Processor codename	Kaby Lake
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	10
Processor ARK ID	96507
Processor package size	42 x 24 mm
Supported instruction sets	SSE4.1, SSE4.2
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	231.8 mm
Width	332.9 mm
Height	23 mm
Weight	1630 g
