Dell Latitude 5285 User Manual

Memory features
Latitude 5285 supports the following memory configurations:
● 4G 1866MHz LPDDR3 - Intel Core i3-7100U
● 8G 1866MHz LPDDR3 - Intel Core i5-7200U/ Intel Core i5-7300U
● 16G 1866MHz LPDDR3 - Intel Core i7-7600U
Verifying system memory in setup
1. Turn on or restart your tablet.
2. When the Dell logo appears, press F2.
Entering BIOS setup message appears.
3. On the left pane, select Settings > General > System Information,
The memory information is displayed on the right pane.
Verifying system memory
Windows 10
1. Click the Windows button and select All Settings
> System .
2. Under System, click About.
Testing memory using ePSA
1. Turn on or restart your tablet.
2. Perform one of the following actions after the Dell logo is displayed:
a. With keyboard—Press F12
b. Press Volume Up button before pressing the Power button to turn on the tablet.
c. Release the Volume Up button, once the power sequence is initiated and ePSA will launch.
The PreBoot System Assessment (PSA) is launched on your tablet.
NOTE:
If you wait too long and the operating system logo appears, continue to wait until you see the desktop. Turn off
the tablet, and try again.
3. Follow the steps in Running ePSA diagnostics.
Display options
This tablet is shipped with 12.3" 1920x1280 Touch with Corning Gorilla Glass, Antireflective and Antismudge display.
Identifying display adapter
1. Type Device manager in the Ask me anything field.
The Display Manager window is displayed.
2. Expand the Display adapters.
The display adapter information is displayed.
Figure 2. display adapter
Technology and components
45

Dell Latitude 5285 Specifications

General

Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Black
Market positioning	Business
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor socket	BGA 1356
Processor threads	4
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.7 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
On-board graphics card	Yes
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Internal memory	8 GB
Memory clock speed	1866 MHz
Memory form factor	On-board
Internal memory type	LPDDR3-SDRAM
Intel segment tagging	Enterprise
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA III
Storage media	SSD
SSD form factor	M.2
Total storage capacity	128 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Pixel pitch	0.135 x 0.135 mm
Display diagonal	12.3 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	340 cd/m²
Display resolution	1920 x 1280 pixels
Native aspect ratio	3:2
Video capturing speed	30 fps
Front camera resolution	2592 x 1944 pixels
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	5 MP
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Pointing device	Touchpad
Keyboard language	US International
AC adapter power	45 W
AC adapter frequency	47/63 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.3 A
Trial software	Microsoft Office, McAfee
Operating system language	Multilingual
Cable lock slot type	Noble
Audio chip	Realtek ALC3253CG
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Processor code	SR2ZU
Processor ARK ID	95443
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Motherboard chipset	Intel SoC

Weight and Dimensions

Depth	208.8 mm
Width	292 mm
Height	14.9 mm
Weight	1196 g
Height (tablet mode)	9.76 mm
Weight (tablet mode)	856 g
