Dell Latitude 5310 2-in-1 User Manual

Next steps
1. Replace the base cover.
2. Replace the microSD card.
3. Follow the procedure in after working inside your computer
WWAN card
Removing the WWAN card
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the microSD card.
3. Remove the base cover.
4. Disconnect the battery cable.
Steps
1. Remove the single (M2x3) screw that secures the WWAN card bracket to the WWAN card [1].
2. Remove the WWAN card bracket from the WWAN card [2].
3. Disconnect the antenna cables from the WWAN card [3].
4. Slide and remove the WWAN card from the WWAN card slot. [4].
30
Disassembly and reassembly

Dell Latitude 5310 2-in-1 Specifications

General

Graphics	Intel UHD Graphics
Operating System	Windows 10 Pro
Bluetooth	Bluetooth 5.1
Processor	10th Gen Intel Core i3/i5/i7
Display	13.3-inch FHD (1920 x 1080) Touch
RAM	Up to 32GB DDR4
Storage	Up to 1TB PCIe NVMe SSD
Battery	4 Cell 60 Whr ExpressCharge™ Capable Battery
Wireless	Intel Wi-Fi 6 AX201
Ports	1 x microSD card reader
Dimensions	305.7 mm x 207.5 mm x 19.6 mm
