Next steps

1. Replace the battery.

2. Replace the base cover.

3. Replace the microSD card.

4. Follow the procedure in after working inside your computer.

LED board

Removing the LED board

Prerequisites

1. Follow the procedure in before working inside your computer.

2. Remove the microSD card.

3. Remove the base cover.

4. Remove the battery.

Steps

1. Disconnect the LED board cable from the connector on the system board [1].

2. Unroute the LED board cable [2].

Disassembly and reassembly

Questions and Answers:

Need help?

Do you have a question about the Dell Latitude 5310 2-in-1 and is the answer not in the manual?

Dell Latitude 5310 2-in-1 Specifications

General

Graphics	Intel UHD Graphics
Operating System	Windows 10 Pro
Bluetooth	Bluetooth 5.1
Processor	10th Gen Intel Core i3/i5/i7
Display	13.3-inch FHD (1920 x 1080) Touch
RAM	Up to 32GB DDR4
Storage	Up to 1TB PCIe NVMe SSD
Battery	4 Cell 60 Whr ExpressCharge™ Capable Battery
Wireless	Intel Wi-Fi 6 AX201
Ports	1 x microSD card reader
Dimensions	305.7 mm x 207.5 mm x 19.6 mm
