Dell Latitude 5310 2-in-1 - Installing the Display Assembly

Installing the display assembly
About this task
NOTE:
Ensure that the hinges are opened to the maximum before replacing the display assembly on the palmrest and
keyboard assembly.
Steps
1. Align and place the system chassis under the hinges of the display assembly [1].
2. Replace the four (M2.5x4) screws that secure the display assembly to the system chassis [2].
