Installing the M.2 SSD
About this task
NOTE:
The computer supports one M.2 2230 solid-state drive or one M.2 2280 solid-state drive at a time. The following
instructions indicates the steps to install only one M.2 SSD card as both the cards utilizes the same slot.
Steps
1. Place the M.2 SSD into the slot on the palmrest [1].
2. Replace the single (M2x2) screw to secure the M.2 SSD to the palmrest [2].
38
Disassembly and reassembly

Dell Latitude 5310 2-in-1 Specifications

General

Graphics	Intel UHD Graphics
Operating System	Windows 10 Pro
Bluetooth	Bluetooth 5.1
Processor	10th Gen Intel Core i3/i5/i7
Display	13.3-inch FHD (1920 x 1080) Touch
RAM	Up to 32GB DDR4
Storage	Up to 1TB PCIe NVMe SSD
Battery	4 Cell 60 Whr ExpressCharge™ Capable Battery
Wireless	Intel Wi-Fi 6 AX201
Ports	1 x microSD card reader
Dimensions	305.7 mm x 207.5 mm x 19.6 mm
