10. Remove the WWAN card.
11. Remove the system board.
NOTE: System board can be removed with heatsink attached.
12. Remove the coin cell battery.
Steps
1. Peel the adhesive tape securing the keyboard and the smartcard reader.
2.
Lift the latch and disconnect the backlit cable and the keyboard cables from the connectors on the touchpad.
84
Disassembly and reassembly
