7. Remove the system fan.
8. Remove the DC-in .
9. Remove the WLAN card.
10. Remove the WWAN card.
11. Remove the system board.
NOTE: System board can be removed with heatsink attached.
12. Remove the coin cell battery.
13. Remove the SmartCard reader board.
About this task
After performing the preceding steps, you are left with the palmrest and keyboard assembly.
Next steps
1. Replace the SmartCard reader board.
2. Replace the coin cell battery.
3. Replace the system board.
NOTE: System board can be replaced with heatsink attached.
4. Replace the WWAN card.
5. Replace the WLAN card.
6. Replace the DC-in.
7. Replace the memory module.
8. Replace the system fan.
9. Replace the speaker.
10. Replace the battery.
11. Replace the base cover.
12. Replace the microSD card.
13. Follow the procedure in after working inside your computer.
94
Disassembly and reassembly

Dell Latitude 5310 2-in-1 Specifications

General

Graphics	Intel UHD Graphics
Operating System	Windows 10 Pro
Bluetooth	Bluetooth 5.1
Processor	10th Gen Intel Core i3/i5/i7
Display	13.3-inch FHD (1920 x 1080) Touch
RAM	Up to 32GB DDR4
Storage	Up to 1TB PCIe NVMe SSD
Battery	4 Cell 60 Whr ExpressCharge™ Capable Battery
Wireless	Intel Wi-Fi 6 AX201
Ports	1 x microSD card reader
Dimensions	305.7 mm x 207.5 mm x 19.6 mm
