Installing the Battery
1. Slide the battery into its slot until it clicks into place.
2. Follow the procedures in After Working Inside Your computer.
Removing the Base Cover
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove battery.
3. Perform the following steps as shown in the illustration:
a. Remove the screws that secure the base cover to the computer [1].
b. Slide the base cover [2].
4. Lift the base cover to remove it from the computer.
10
