e. WWAN card
f. plamrest
g. SSD card
h. keyboard
i. keyboard trim
j. base cover
k. battery
5. Follow the procedures in After Working Inside Your computer.
Removing the Coin-Cell Battery
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
c. keyboard trim
d. keyboard
e. SSD card
f. palmrest
3. Perform the following steps as shown in the illustration:
a. Disconnect the coin-cell cable from the computer [1].
b. Lift the coin-cell battery from the computer [2].
Installing the Coin-Cell Battery
1. Place the Coin-cell battery on the computer.
2. Connect the coin-cell battery cable to the computer.
3. Install:
a. plamrest
b. SSD card
c. keyboard trim
d. keyboard
