Removing the Palmrest
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
c. SSD card
d. keyboard trim
e. keyboard
3. Remove the screws that secure the palmrest assembly and flip the computer.
4. Perform the following steps as shown in the illustration:
a. Lift the latch that secures the keyboard and touch cable to the computer [1].
b. Disconnect the keyboard and touch cable to the computer [2].
c. Remove the screws that secure the palmrest assembly to the computer [3].
16
