Dell Latitude E7250 - Installing the Speakers; Removing the Display-Hinge Cover

Installing the Speakers
1. Align the speakers to their original position and tighten the screws to secure the speakers to the
computer.
2. Route the speaker cable on the computer and connect it to the system board.
3. Install:
a. SIM board
b. plamrest
c. keyboard
d. keyboard trim
e. SSD card
f. base cover
g. battery
4. Follow the procedures in After Working Inside Your computer.
Removing the Display-Hinge Cover
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
c. keyboard trim
d. SSD card
e. palmrest
3. Remove the screws that secure the display-hinge cover to the computer.
4. Perform the following steps as shown in the illustration:
a. Remove the screws that secure hinge to the system board [1].
b. Lift the Hinge from the computer [2].
