Dell Latitude E7250 - Installing the Keyboard Trim; Removing the Keyboard

Installing the Keyboard Trim
1. Align the keyboard trim to its slot.
2. Press along the sides of the keyboard trim until it clicks in place.
3. Install battery.
4. Follow the procedures in After Working Inside Your computer
Removing the Keyboard
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
c. keyboard trim
3. Perform the following steps as shown in the illustration:
a. Lift the battery bay that secures the keyboard to the computer [1].
b. Lift the latch that secure the keyboard cable to the computer [2].
c. Disconnect the keyboard cable the computer [3].
