Installing the Base Cover
1. Place the base cover to align with the screw holes correctly on the computer.
2. Tighten the screws to secure the base cover to the computer.
3. Install battery.
4. Follow the procedures in After Working Inside Your computer.
Removing the SSD Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
3. Perform the following steps as shown in the illustration:
a. Remove the screws that secure the SSD card to the computer [1].
b. Lift and remove the SSD card from the computer [2].
11
