Dell Latitude E7250 - Installing the Display-Hinge Cover; Removing the Display Assembly

Installing the Display-Hinge Cover
1. Place the display-hinge cover and tighten the screws to secure the display-hinge cover to the system
board.
2. Tighten the screws that secures hinge cap to the computer.
3. Instal:
a. plamrest
b. keyboard
c. keyboard trim
d. SSD card
e. base cover
f. battery
4. Follow the procedures in After Working Inside Your computer.
Removing the Display Assembly
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
c. keyboard trim
d. keyboard
e. SSD card
f. palmrest
3. Disconnect the cable.
21
