Installing the Display Assembly
1. Insert the display and wireless antenna cables through the holes on the base chassis and connect
them.
2. Place the display assembly onto the computer.
3. Tighten the screws on both sides to secure the display assembly.
4. Route and connect the display cables through the routing channel.
5. Connect the WWAN and WLAN cables to the computer.
6. Install:
a. plamrest
b. keyboard
c. keyboard trim
d. SSD card
e. base cover
f. battery
7. Follow the procedures in After Working Inside Your computer.
Removing the System Board
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. battery
b. base cover
c. keyboard trim
d. keyboard
e. SSD card
f. palmrest
g. WWAN card
h. WLAN card
